Centrifugal concentrator

Product Overview
Centrifugal concentrator is an advanced mineral processing equipment that adopts centrifugal force to strengthen gravity separation principle, and realizes efficient separation of minerals through the patented design of enrichment cone structure. This equipment is especially suitable for gold recovery, can effectively capture the loss of monomer gold in traditional re-election equipment (such as sliding gold blanket, jigger), alluvial gold recovery rate can reach more than 99%, and the selection ratio is as high as 1000 times. At the same time, it is suitable for rock gold ore and tailings recovery, and can completely replace the amalgamated gold extraction method, which is the best choice for environmentally friendly gold beneficiation.

Core Technology

🔧 Innovative sorting principle

• Centrifugal enhanced sorting: 200-300G centrifugal force field to expand the mineral gravity difference.

• Backwash water control system: precise control of light/heavy mineral separation boundary

• Ribbed flute design: patented enrichment cone structure improves the capture rate of gold particles.

⚙️ Intelligent Control System

• Fully automatic discharge: one-button operation, eliminating concentrate loss due to manual intervention.

• Closed operation: no exposure, traceable recovery rate

• Frequency conversion speed control: optimize centrifugal force parameters according to mineral properties.

Core Advantages

✅ Excellent sorting performance

• 99% recovery: especially good at capturing micro-fine grained monomer gold

• 1000:1 concentrate ratio: significantly increase the concentrate grade.

• 0.04mm recovery limit: breaking through the lower limit of traditional re-election equipment.

✅ Intelligent and environmentally friendly design

• Full-automatic ore discharge: eliminating human losses and reducing labor costs.

• Zero chemical addition: complete physical sorting, no environmental pollution.

• Closed structure: traceability of precious metals.

✅ Economic and efficient

• 40% energy saving: optimized energy consumption design

• Wear-resistant components: 3 times longer life of key components.

• Plug and Play: Seamless integration into existing beneficiation systems.

Application Areas

• Alluvial Gold Ore: Replacing traditional equipment such as chute and jigger.

• Rock Gold Ore: Highly efficient recovery at -0.074mm grinding size.

• Tailings re-election: recover lost gold from old tailings.

Technical Parameters

Note: The cycle of cleaning concentrate varies according to the type of ore, rock gold ore is recommended to be cleaned every 1-3 hours, and alluvial gold ore is recommended to be cleaned every 2-6 hours.
